性能特点Features
外框：镀锌或铝型材。
滤料：采用活性碳浸泡聚酯无纺布制成，钢筋支撑架，强度好，滤料可更换。
效率：（EN779:2002）G4；
（ASHRAE 52.2:2007）MERV7。
建议终压损：250Pa。
Frame:Mill-finished aluminium profile.
Media: Made of polyester non-woven soaked in activated charcoal, effectivelyremove a variety of odors in the air, High strength, Replaceable filter media.
Efficiency:(EN779:2002 filter class)G4;
(ASHRAE 52.2:2007 filter class)MERV8.
Recommended final pressure drop:250Pa.
应用 Applications
安装空间紧张，需要去除异味气体污染的通风空调系统
机场，酒店，写字楼，大型商场等商用和民用建筑
博物馆，图书馆，等送风空调系统
Tight installation space，Ventilation and air conditioning systems need to remove the odor of gas contamination
Airports, luxury hotels, office buildings, large shopping malls and other commercial and civil
Air-conditioning system of museums, libraries, etc.
常用规格 Common Specifications
型 号 Model | 外形尺寸 Dimensions | 额定风量 Rated Air Flow (m3/h) | 初始压降 Initial Pressure Drop (Pa) |
W×H×D (mm) | |||
SPAC-24×24×2 | 595×595×45 | 3400 | 135 |
SPAC-12×24×2 | 290×595×45 | 1700 | |
SPAC-20×24×2 | 493×595×45 | 3200 | |
SPAC-20×20×2 | 493×493×45 | 3200 | |
SPAC-12×20×2 | 290×493×45 | 1700 | |
SPAC-20×24×1 | 493×595×20 | 1900 | 85 |
SPAC-20×20×1 | 493×493×20 | 1900 | |
SPAC-12×20×1 | 290×493×20 | 900 | |
SPAC-24×24×1 | 595×595×20 | 2000 | |
SPAC-12×24×1 | 290×595×20 | 1000 |
1、若遇规格、结构变更，以本公司提供的新数据为准
2、本公司接受非标准规格的订货
1. If you meet specifications, structural changes, the company provides the newest data shall prevail
2.We accept the orders of non-standard specifications
