性能特点Features
安装框架:：冷轧钢板喷塑或不锈钢 。
碳筒材质：镀锌钢板或不锈钢，碳筒金属壳体可重复使用。
填充滤料：颗粒活性炭经过特殊化学配方处理，吸附能力强、去除效率高，性能可靠。
Install the framework：Electrostatic spraying of cold rolled steel or stainless steel.
Carbon tube Material: galvanized steel or stainless steel,The metal shell of the carbon tube reusable
Media：Using activated charcoal particles with a special chemical formula treatment,Reliable performance with high adsorption capacity and removal efficiency.
应用Applications
为商用或工业用中央空调和集中通风系统设计，清除空气中的异味(恶臭)和有害气体
可根据实际需要提供多种特制活性炭材料，如挥发性有机化合物，酸性、碱性气体，甲醛，汞蒸气，放射性气体
Exclusively designed for commercial or industrial central air conditioning and central ventilation system, eliminate the odor (smell)and harmful gases in air.
A variety of special activated charcoal materials can be provided according to the actual needs, such as elimination of acid gas,alkaline gas, formaldehyde, mercury vapor as well as radioactive gases.
常用规格 Common Specifications
型号 Model | 炭筒尺寸Cylinder Dimensions (mm) | 组合单元尺寸 Modular Dimensions (mm) | 碳筒数 No. of Cylinder | 活性碳含量Charcoal Content (kg) | 初始压损Pressure Drop (Pa) | 风量 Air Flow (m3/h) | ||
W | H | D+70 | ||||||
SCAC-330-16 | Ф145×330 | 610 | 610 | 403 | 16 | 24 | 135 | 3600 |
SCAC-330-12 | 508 | 610 | 12 | 18 | 135 | 2700 | ||
SCAC-330-8 | 305 | 610 | 8 | 12 | 135 | 1800 | ||
SCAC-330-4 | 305 | 305 | 4 | 6 | 135 | 900 | ||
SCAC-450-16 | Ф145×450 | 610 | 610 | 478 | 16 | 28.8 | 110 | 3600 |
SCAC-450-12 | 508 | 610 | 12 | 21.6 | 110 | 2700 | ||
SCAC-450-8 | 305 | 610 | 8 | 14.4 | 110 | 1800 | ||
SCAC-450-4 | 305 | 305 | 4 | 7.2 | 110 | 900 | ||
SCAC-480-16 | Ф145×480 | 610 | 610 | 553 | 16 | 35.2 | 90 | 3600 |
SCAC-480-12 | 508 | 610 | 12 | 26.4 | 90 | 2700 | ||
SCAC-480-8 | 305 | 610 | 8 | 17.6 | 90 | 1800 | ||
SCAC-480-4 | 305 | 305 | 4 | 8.8 | 90 | 900 | ||
SCAC-600-16 | Ф145×600 | 610 | 610 | 673 | 16 | 43.2 | 70 | 3600 |
SCAC-600-12 | 508 | 610 | 12 | 32.4 | 70 | 2700 | ||
SCAC-60-8 | 305 | 610 | 8 | 21.6 | 70 | 1800 | ||
SCAC-60-4 | 305 | 305 | 4 | 10.8 | 70 | |||
1、若遇规格、结构变更，以本公司提供的新数据为准
2、本公司接受非标准规格的订货
1. If you meet specifications, structural changes, the company provides the newest data shall prevail
2.We accept the orders of non-standard specifications
上海新锐过滤材料有限公司
